Regional Sustainability >

2021 , Vol. 2 >Issue 3: 264 - 279

DOI: https://doi.org/10.1016/j.regsus.2021.11.005

Full Length Article

Coupling analysis of short-term weather and runoff in an arid lake basin of China

  • WANG Jie ,
  • LIU Dongwei ,
  • TIAN Songni ,
  • HU Yuehong ,
  • MA Jiali ,
  • WANG Lixin
Expand
  • aSchool of Ecology and Environment, Inner Mongolia University, Hohhot, 010021, China
    bInner Mongolia Key Laboratory of River and Lake Ecology, Hohhot, 010021, China
    cKey Laboratory of Ecology and Resource Use of the Mongolian Plateau, Ministry of Education of China, Hohhot, 010021, China

Received date: 2021-07-24

  Revised date: 2021-10-16

  Accepted date: 2021-11-10

  Online published: 2021-12-24

Fold

Abstract

Changes in the weather will cause variations in the hydrological system. Arid areas, with fragile hydrological systems, are very sensitive to changes in the weather, so the coupling analysis of short-term weather and runoff in arid areas is of great significance. The Daihai Lake is a closed inland lake in an arid area of China. In this paper, Weather Research and Forecasting model mode-Hydrological module (WRF-HYDRO) is used to simulate the coupling of weather and hydrology in the Daihai Lake Basin. Regional optimization of WRF-HYDRO is carried out to determine the optimal parameters. The optimal WRF-HYDRO model is applied to couple the short-term weather and runoff in the Daihai Lake Basin to reproduce several rainstorm and flood events. It is found that runoff infiltration parameter (REFKDT) in WRF-HYDRO is the parameter that has the most severe effect on runoff in the Daihai Lake Basin. WRF-HYDRO can capture the rainstorm moment of the rainstorm events in the Daihai Lake Basin, especially the first rainstorm moment, and its simulation accuracy is good. WRF-HYDRO has a strong ability to capture flood peak, but there is a discrepancy between WRF-HYDRO flood peak and Soil Conservation Service Curve Number (SCS-CN) calculation result at the flood peak moment. The northern part of Zuoyun County should guard against the occurrence of flood disaster in wet season. The coupling of weather and hydrology can not only make up for the lack of runoff data in arid basins, but also provide a basis for water resources management and disaster prevention and mitigation in the basins.

Key words： Rainfall simulation; Runoff simulation; WRF-HYDRO; Soil Conservation; Service Curve Number; Flood peak; Parameter calibration; Daihai Lake Basin

Cite this article

WANG Jie , LIU Dongwei , TIAN Songni , HU Yuehong , MA Jiali , WANG Lixin . Coupling analysis of short-term weather and runoff in an arid lake basin of China[J]. Regional Sustainability, 2021 , 2(3) : 264 -279 . DOI: 10.1016/j.regsus.2021.11.005

References

[1] Abula, A., Wang, Y., Ling, H., et al., 2019. Analysis of water resources change trend and water use efficiency in Tarim River Basin. Journal of Shihezi University (Natural Science). 37(1), 112-120 (in Chinese).
[2] Al-Ghobari, H., Dewidar, A., 2021. Integrating GIS-based MCDA techniques and the SCS-CN method for identifying potential zones for rainwater harvesting in a semi-arid area. Water. 13(5), 704.
[3] Chao, L.J., Zhang, K., Yang, Z.L., et al., 2021. Improving flood simulation capability of the WRF-Hydro-RAPID model using a multi-source precipitation merging method. J. Hydrol. 592, 125814.
[4] Chen, J.Q., Lv, J., Li, N., et al., 2019. External groundwater alleviates the degradation of closed lakes in semi-arid regions of China. Remote. Sens. 12(1), 1-20.
[5] Chen, J.S., Ji, B.C., Liu, Z., et al., 2013. Isotopic and hydro-chemical evidence on the origin of groundwater through deep-circulation ways in Lake Daihai region, Inner Mongolia plateau. J. Lake Sci. 25(4), 521-530.
[6] Darji, K., Prakash, I., Pham, B., 2020. Runoff estimation of machhu and watrak rivers basins of gujarat India using SCS-CN method and GIS. Indian J. Ecol. 47(3), 726-732.
[7] Dudhia, J., 1989. Numerical study of convection observed during the winter monsoon experiment using a mesoscale two-dimensional model. J. Atmos. Sci. 46(20), 3077-3107.
[8] Gochis, D., Yu, W., Yates, D., 2013. The NCAR WRF-Hydro Technical Description and User’s Guide (Version 1.0). Boulder: NCAR.
[9] Hao, W., Qin, D.Y., Wang, J.H., et al., 2004. Study on water resources carrying capacity in northwest inland arid area in China. J. Nat. Resour. 19(2), 151-159.
[10] Hong, S.Y., Noh, Y., Dudhia, J., 2006. A new vertical diffusion package with an explicit treatment of entrainment processes. Mon. Weather Rev. 134(9), 2318.
[11] Hu, L., Lu, W., 2014. Analysis on water environment status and necessity of water supplement in Daihai basin of Liangcheng County. Inner Mongolia Water Resources. 1, 109-110 (in Chinese).
[12] Lahmers, T.M., Gupta, H., Castro, C.L., et al., 2019. Enhancing the structure of the WRF-hydro hydrologic model for semiarid environments. J. Hydrometeorol. 20(4), 691-714.
[13] Lin, Y.L., Farley, R.D., Orville, H.D., 1983. Bulk parameterization of the snow field in a cloud model. J. Climate Appl. Meteor. 22(6), 1065-1092.
[14] Liu, J., Bray, M., Han, D.W., 2013. Exploring the effect of data assimilation by WRF-3DVar for numerical rainfall prediction with different types of storm events. Hydrol. Process. 27(25), 3627-3640.
[15] Liu, Y.C., Liu, J., Li, C.Z., et al., 2019. Advances of WRF-hydro and its application in hydrological simulation and forecasting. Water Resources and Power. 37(11), 1-5 (in Chinese).
[16] Liu, Y.C., Liu, J., Li, C.Z., et al., 2021. Parameter sensitivity analysis of the WRF-hydro modeling system for streamflow simulation: a case study in semi-humid and semi-arid catchments of Northern China. Asia Pac. J. Atmos. Sci. 57(3), 451-466.
[17] Liu, Z.H., Xu, J.H., Chen, Z.S., et al., 2014. Multifractal and long memory of humidity process in the Tarim River Basin. Stoch. Environ. Res. Risk Assess. 28(6), 1383-1400.
[18] Mahmood, K., Qaiser, A., Farooq, S., et al., 2020. RS- and GIS-based modeling for optimum site selection in rain water harvesting system: an SCS-CN approach. Acta Geophys. 68(4), 1175-1185.
[19] Meng, X.Y., Meng, B.C., Wang, Y.J., et al., 2015. Influence of climate change and human activities on water resources in ebinur lake in recent 60 years. J. China Hydrol. 35(2), 90-96.
[20] Mlawer, E.J., Taubman, S.J., Brown, P.D., et al., 1997. Radiative transfer for inhomogeneous atmospheres: RRTM, a validated correlated-k model for the longwave. J. Geophys. Res. Atmos. 102(D14), 16663-16682.
[21] Naabil, E., Lamptey, B.L., Arnault, J., et al., 2017. Water resources management using the WRF-Hydro modelling system: case-study of the Tono Dam in West Africa. J. Hydrol. Reg. Stud. 12, 196-209.
[22] Qiao, P., Qin, Y., Liu, Z.H., 2011. A spatially distributed snowmelt model based on energy balance. J. China Hydrol. 31(3), 22-26.
[23] Reda, K.W., Liu, X.C., Tang, Q.H., et al., 2021. Evaluation of global gridded precipitation and temperature datasets against gauged observations over the upper tekeze river basin, Ethiopia. J. Meteorol. Res. 35(4), 673-689.
[24] Rummler, T., Arnault, J., Gochis, D., et al., 2019. Role of lateral terrestrial water flow on the regional water cycle in a complex terrain region: investigation with a fully coupled model system. J. Geophys. Res. Atmos. 124(2), 507-529.
[25] Silver, M., Karnieli, A., Ginat, H., et al., 2017. An innovative method for determining hydrological calibration parameters for the WRF-Hydro model in arid regions. Environ. Model. Softw. 91, 47-69.
[26] Sun, M.K., Li, Z.J., Liu, Z.Y., et al., 2020a. Application of WRF-Hydro modeling system in Chenhe Basin and comparison with Xin’anjiang model. J. Lake Sci. 32(3), 850-864.
[27] Sun, M.K., Li, Z.J., Yao, C., et al., 2020b. Evaluation of flood prediction capability of the WRF-hydro model based on multiple forcing scenarios. Water. 12(3), 874.
[28] Tian, J.Y., Liu, J., Yan, D.H., et al., 2019. Ensemble flood forecasting based on a coupled atmospheric-hydrological modeling system with data assimilation. Atmos. Res. 224, 127-137.
[29] Wang, M., He, X., Guo, H., 2020. Influence of land use data resolution on SCS model in runoff simulation. Pearl River. 41(10), 30-35 (in Chinese).
[30] Wang, S.H., Bai, M.X., Chen, J.Y., et al., 2019. Research on the ecological protection and restoration of mountain-river-forest-farmland-lake-grassland system in typical farming-pastoral ecotone: taking Daihai Lake Basin in Inner Mongolia as an example. Journal of Environmental Engineering Technology. 9(5), 515-519 (in Chinese).
[31] Wang, Y.J., Qin, D.H., 2017. Influence of climate change and human activity on water resources in arid region of Northwest China: an overview. Adv. Clim. Change Res. 8(4), 268-278.
[32] Wehbe, Y., Temimi, M., Weston, M., et al., 2019. Analysis of an extreme weather event in a hyper-arid region using WRF-Hydro coupling, station, and satellite data. Nat. Hazards Earth Syst. Sci. 19(6), 1129-1149.
[33] Xiao, B., Wang, Q.H., Fan, J., et al., 2011. Application of the SCS-CN model to runoff estimation in a small watershed with high spatial heterogeneity. Pedosphere. 21(6), 738-749.
[34] Yang, M., Sun, X.H., 2011. Research on SCS-CN in Lanhe Basin distributed rainfall runoff event. Appl. Mech. Mater. 105-107, 1476-1479.
[35] Yucel, I., Onen, A., Yilmaz, K.K., et al., 2015. Calibration and evaluation of a flood forecasting system: utility of numerical weather prediction model, data assimilation and satellite-based rainfall. J. Hydrol. 523, 49-66.
[36] Yun, M., Yan, S., Gong, J., 2019. Analysis of inflow runoff in Daihai. Inner Mongolia Water Resources. (5), 21-22 (in Chinese).
[37] Zhang, Z.Y., Arnault, J., Wagner, S., et al., 2019. Impact of lateral terrestrial water flow on land-atmosphere interactions in the Heihe River basin in China: fully coupled modeling and precipitation recycling analysis. J. Geophys. Res. Atmos. 124(15), 8401-8423.
[38] Zhou, X., Wang, Q., Zhang, D., et al., 2021. Runoff estimation of ridge-furrow rainwater harvesting with maize straw biochar application based on soil conservation service curve number (SCS-CN) model in semiarid regions of China. Arid Land Geography. 44(1), 99-108 (in Chinese).
